Product details
TD600high-speed rapier velvet loom is used in Cleaning flannelette, velveteen, velvet, plush, industrial cloth and other fabrics, including sofa flannelette, car decoration flannelette, curtain flannelette, clothing velvet fabric, clothing velvet fabric, home textile velvet, light blanket, prayer blanket.
Sofa Velvet
Car Decoration Velvet
Curtain Velvet
Clothing Velvet Fabric
Prayer Blanket
Main technical parameters
| Nominal reed width | 190,230,260,280,320,340(cm) |
| Loom speed | Design speed500 RPM, Optimal speed 250-350 rpm |
| Piling height | 0--10(mm) |
| Suitable Yarn | Cotton 3-80s, Filament 20-1000D,Man-made fiber 5-500Tex |
| Main drive | High Power Asynchronous Motor Drive,stepless speed change by inverter |
| Pile feeding | Optional mechanical feeding device or servo electronic feeding device |
| Shedding | Electronic Dobby,with levers up to 20 pcs |
| Beating up | Double-side drive, conjugate cam beating-up mechanism |
| Weft insertion | Space four-bar linkage drive, single cloth- fell weft insertion device |
| LET OFF | Servo Electronic Let off |
| TAKE UP | Servo Electronic take up |
| Pick finding | Slow motion Automatic pick finding Device |
| Color selecting | Electronic color selection device, up to 8 colors |
| Warp beam | Ground beam 中800mm,Pile beam 中800 or 1000mm |
| Batching | Outer double Batching device,Max800for each batching device |
| Weft control | Electronic weft detector high sensitivity. anti-double weft, up to 8 colors |
| Warp Stop device | electronic warp stop device |
| Lubrication device | closed cycle lubrication device. Equipped with oil pressure and oil level alarm device |
| Selvage formation device | Independent electronic LENO device |
| Optional device | electronic Selvage jacquard device, Hot-melt Selvage device, etc |
