Product details
Optimum comber parts and movements makes the more stable successful, which also results in less consumption, lower noise, smaller vibration, and more stable performance.The optimum of processing enables the sufficient combing of the fiber, it ensures the fibre’s length and parallelism. Even in the state of highest output at high speed, the piecing in the tuff is optimal, the processing scope is wider.
Optimize the air flow’s adjustment and control, it has the noil air complementary setting, it reduced the impact at high speed. It reduces the consumption. More flexible and new type operation system, everything is considered from the customer’s benefits, it designs more key parts which had online monitor control performance. It has active function of improving the quality, accelerating the material utilization percentage, reducing the consumption, enhancing the back processing’s running performance, lessening the power consumption mostly.
With the new type of visual and friendly operation screen, which results in simple operation and more convenient administration for customer. It offers perfect manufacturing administration data-base mode which had function of central collecting standard, it also supply the service of software continued upgrade or personal performance tailor according to the customer’s requirements.
Main technical parameters
No. of combing heads | 470mm |
Gauge | 300mm |
Feed lap width | 650mm |
Feed lap max.Diameter | 60-80g/m |
Suitable cotton fiber length | 25~51mm |
Waste percentage | 8-25% |
Feeding mode | Foward feed, backward feed |
Feed length | 4.3,4.7 |
Cylinder Type | 90 |
Theoretical speed | 450nips/min |
Output length | 26.68mm |
Drafting system Type | 3-over-5 with pneumatic weighting |
Drafting times | Total draft:9-19.3 |
Drafting distance | Main drafting 32.5-50.5mm |
Coiling mechanism | single can, single coiling |
Specification of can | 600mm x H1200mm |
Delivered combed silver weight | 3-6g/m |
Theoretical output | 75kg/hour |
Suction system | Central integral suction mainly |
Compressed air Pressure | 0.6-0.8mpa |
Compressed air consumption | 0.5per hour |
Main moto(inverter) | 5.5kw |
Brush motor | 1.1kw |
Weight | 5.25T |
Dimension | 7167 x 2042 x 1700 (L X W X H) |
