X20-DI-4371 B&R 4 digital inputs Module X20DI4371
Inhouse product
X20-DI-4371 B&R 4 digital inputs Module X20DI4371. Therefore, it is X20 digital input module with 4 inputs and also 24 VDC, sink, and configurable input filter with 3-wire connections. Moreover, the modules are X20 modules with a safety coating for the electronics component.
This also saves the X20c modules from contraction and destructive gases. B&R X20DI4371 Digital Inputs Module price in BD. BD Engineering Solution provides an industrial total solution.
B&R X20DI4371 Digital Inputs Module
| Brand Name | B&R |
| Product No | X20DI4371 |
| Product type | X20 Digital Counter Module |
| I/O module type | 4 digital inputs with 24 VDC |
| ID code | 0x1B92 |
| Indicators type | I/O function, operating state and a module status |
| Bus Power consumption | 0.14 |
| Internal I/O Power consumption | 0.59 |
| Nominal Voltage for Digital inputs | 24 VDC |
| Input voltage | 24 VDC and -15% / +20% |
| Run/error Module | Yes, with a good status LED and software |
| Input current | 3.75 mA |
| Input circuit type | Sink |
| Input resistance range | 6.4 kΩ |
| Operation Temp. Horizontal installation | -25 to 60°C |
| Operation Temp. Vertical installation | 25 to 50°C |
| Humidity | 5 to 95% (non-condensing) |
Moreover, the X20 System bus modules are used for different types of platforms for various machine variations. Here, the machine design helps the electronic modules which are used. Above all, the software for the module admits the layout and gives the required functions. As a result, it is used for handling a number of machine types that couldn’t work properly.
