SIEMENS SIMATIC S7-1200 Signal Module – 6ES7223-1PL22-0XA0

16 Digital Inputs (24V DC), 16 Relay Outputs (2A/point)

The SIEMENS 6ES7223-1PL22-0XA0 is a powerful digital I/O signal module for the SIMATIC S7-1200 PLC system. It provides 16 digital inputs (24V DC) and 16 relay outputs, each rated at 2A per point. This all-in-one I/O expansion module is ideal for flexible and space-saving integration of a large number of field signals into automation systems.

Key Features:

• Product Type: Signal Module (SM 1223)

• System Compatibility: SIMATIC S7-1200

• Inputs: 16 digital inputs (24V DC)

• Outputs: 16 relay outputs (max. 2A per channel)

• Galvanic isolation between channels and system bus

• Compact DIN rail mountable module

• Programmable via TIA Portal

• Operating Temperature: -20°C to +60°C

• Approvals: CE, UL, cULus
