Schneider Electric Base rack M340 -12 slots panel mounting BMXXBP1200

The Schneider Electric Modicon M340 Base Rack BMXXBP1200 is a 12-slot backplane designed for the Modicon M340 Programmable Automation Controller (PAC) system. The 12 slots for accommodating Modicon M340 modules such as the CPU, power supplies, I/O modules (discrete and analog), and communication modules.

Technical Specification:

• Backplane Bus: Which provides the communication and power distribution backbone for the M340 system.
• Connectors: Equipped with connectors to interface with the various M340 modules. It typically includes one XBE connector for potential rack expansion.
• Power Consumption: The rack itself has a low power consumption (around 0.74W to 1.68W depending on the specific version).
• Compatibility: The Modicon M340 series of processors (BMXP34), power supplies (BMXCPS), and I/O modules (BMXX80).

Summery:

The BMXXBP1200 provides the physical and electrical infrastructure to build a Modicon M340 control system with up to 12 modules. Its panel mounting design allows for secure installation within control cabinets or on machinery.
