Roving Frame Simplex Spinning Machine FA471
Inhouse product
Product details
FA471 Roving frame simplex spinning machine has three-shaft linkage computerized type high speed suspend flyer roving frames adopt the advanced computer numerical control technique,getting rid of the cone drum structure,mechanical forming and direction transposition structures of former flyer frames.
The automaticity is high, simplicity of operator, services conveniently, depth wool spinning customer high praise.
The optimization design new differential mechanism he change transmission stressful condition, increased the design manufacture precision, the solution vibrates in a big way, elevates, the oil leak to be serious warm, the bearing easy to damage technical difficult problem.
Main technical parameters
Suitable for square fiber length | 60-200mm |
Drawing multiple | 4-16 |
Viscosity range | 10-40twist/m |
The scope of Article | 0.3-1g/m |
Feeding range | 5-15g/m |
Constant speed | the maximum mechanical speed 1200RPM Maximum process speed 900RPM |
Drafting system | A complete unit Chinese brand drafting sysrem (spring weighting arm). |
Roller diameter(mm) | φ28.5,φ28.5 |
Top roller diameter(mm) | φ25,φ28 |
Drafting range | 4.2-12 |
Mechianical spindle speed(r/min) | 1600 |
Twist range(twist/m) | 18.0-80 |
Bobbin dimentions(mm) | φ45×445 |
Take up package dimentions(mm) | φ152×40 |
Related products
Roving frame for wool spinning FB479
