Large Package Winding Machine TD-MLD
Inhouse product
Product details
It’s designed for winding cotton yarn, chemical fiber, and filament, low stretch yarn to large package of 8 or 10 inch.
Vertical winder path with no inflection point, little friction and less hairiness. It is appropriate for high speed winding.
Double points tension control system with micro motors, uniform yarn tension. The forming of cheese is good and it can waxing automatically.
Ni-P alloy groove drum with optimized groove shape, which have the advantages of good anti-overlapping characteristics, light weight, good wear resistance, and static elimination.
Single winding motor control for each spindle, electronic fixed-length, single spindle automatic stop while yarn breaking or fully filled.
Main technical parameters
Item | Technical Parameters |
Mechanical speed | Up to 800m/min(depending on yarn quality and count) |
Package bobbin | 0°，3°30’ |
Package diameter | Up to φ 290 mm |
Package weight | Up to10kg |
Yarn / count | Cotton. flax, wool,silk, chemical fiber /Ne 6…180 |
Power consumption | Installed power: 100W/spindle for 8 inch machine, 180W/spindle for 10 inch machine. |
Tensioner | Each spindle has a yarn tensioner and a waxing unit |
Auto stop while yarn break | With electronic yarn sensor, the spindle will stop when yarn break |
Automatic length fixing | Automatic length fixing,max:999999m |
Slow start | For smooth start and better winding quality, supporting individual slow start for each spindle |
Electronic yarn clearer | Optional |
Air splicer | Optional |
Travelling blower | Optional, power consumption1.1KW |
External dimensions | (8 inch with 4 spindles )1500mm×408mm×1510mm, (10 inch with 4 spindles) 1700×408mm×1510mm |
Weight of whole machine | 8 inches with 4 spindles: 105kg 10 inches with 4 spindles: 115kg |
Power supply | Single phased 220V ，50/60HZ |
