The 1769-OF4 CompactLogix 4 Pt AO Module Allen Bradley. The Allen-Bradley 1769-OF4 Compact I/O 4-Channel single-ended Analog Current/Voltage Output Module, 120 mA at 5V DC; 170 mA at 24V DC. Most of the HMI of Allen Bradley product available in BD ENGINEERING

The Allen Bradley CompactLogix 1400 series, specifically the 1769-OF4 module, is a 4-point analog output module. This module is used within the CompactLogix series for industrial automation and control applications.

Here are some key details about the 1769-OF4 module:

Key Features:

1. Output Channels:
   • The 1769-OF4 module has 4 analog output channels.
   • Each channel can be configured for either voltage or current output.
2. Voltage Output Range:
   • 0 to 10V DC
   • -10 to 10V DC
3. Current Output Range:
   • 0 to 20 mA
   • 4 to 20 mA
4. Resolution:
   • 16-bit resolution for precise analog signal generation.
5. Accuracy:
   • High accuracy for both voltage and current outputs.
6. Isolation:
   • Provides electrical isolation between the module and the backplane, ensuring safety and reliability in various industrial environments.
7. Compatibility:
   • Designed to work seamlessly with the CompactLogix family of programmable automation controllers (PACs).
8. Configuration:
   • Configurable via RSLogix 5000 or Studio 5000 Logix Designer software.

Applications:

• Process control systems
• Industrial automation
• Motion control
• Data acquisition systems

Technical Specifications:

• Power Supply: Draws power from the CompactLogix backplane.
• Update Rate: Fast update rate suitable for real-time control applications.
• Temperature Range: Operates in a wide temperature range, suitable for harsh industrial environments.
• Diagnostics: Built-in diagnostics for easy troubleshooting and maintenance.
