Allen Bradley 1734-IT2I Module with terminal base 1734-TBCJC

The Allen Bradley 1734-IT2I module is a part of the POINT I/O system by Rockwell Automation, designed for temperature input applications. The 1734-IT2I module specifically handles two isolated thermocouple inputs. It supports various types of thermocouples and provides high accuracy temperature measurement suitable for industrial automation applications.

Technical 1734-IT2I Module:

• Function: Two isolated thermocouple inputs
• Supported Thermocouples: J, K, T, E, R, S, B, N, C
• Resolution: 16 bits
• Input Isolation: Channel-to-channel isolation
• Accuracy: ±0.5°C for most thermocouple types
• Temperature Range: Dependent on the thermocouple type
• Calibration: Factory calibrated, no field calibration required

• The 1734-TBCJC Terminal Base:

  • The Compatibility: Designed to work specifically with the 1734-IT2I module
  • Terminal Points: 8 points (4 per thermocouple channel)
  • Color-Coded Terminals: To match specific thermocouple types, ensuring proper connection
  • DIN Rail Mounting: For easy installation and removal
  • Dimensions: Compact design to fit within the POINT I/O system structure

  Installation and Setup Guide:

  • Install the 1734-TBCJC terminal base on the DIN rail in the desired location within the POINT I/O system.
  • Connect the thermocouple leads to the appropriate terminals on the 1734-TBCJC. Ensure correct polarity and match the thermocouple type with the corresponding color-coded terminal.
  • Use Rockwell Automation’s software tools (like RSLogix 5000 or Studio 5000) to configure the module. Set up the thermocouple types, calibration parameters, and any required scaling or alarms.
  • Test the system to ensure proper functionality. Check the readings from the thermocouples to confirm accuracy and reliability.
  • Integrates into the POINT I/O system, providing a compact and modular solution. The official Allen Bradley documentation and user manuals. This will provide comprehensive guidelines on wiring, configuration, and troubleshooting to ensure optimal performance of your 1734-IT2I module and 1734-TBCJC terminal base.
