Description:
The MS 495-75 is a high-capacity thermal-magnetic manual motor starter designed to protect motors up to 37 kW. It combines precise overload, short circuit, and phase failure protection with reliable manual ON/OFF switching, making it suitable for demanding industrial motor control applications.

Application:
Best suited for large industrial motors, heavy machinery, and motor control centers where safe, reliable, and fuseless motor protection is essential.

Objective:
To protect high-power motors from overloads and short circuits, reduce equipment failure, ensure operational safety, and allow for easy manual control.

✔️ Key Features:

• Current Range: 57.00 – 75.00 A

• Motor Power Rating: Up to 37 kW (400 V, AC-3)

• Trip Class: Class 10 – fast thermal response for overload protection

• Short Circuit Protection: Up to 25 kA breaking capacity

• Phase Loss Protection: Built-in phase failure detection

• Manual Operation: Rotary ON/OFF handle with trip-free mechanism

• Construction: Compact, DIN rail mountable, industrial-grade casing

• Safety: IP20 protection, finger-safe terminals

• Durability: Over 100,000 mechanical operations

• Expandable Options: Compatible with auxiliary contacts, shunt trips, and undervoltage releases
