Description:
The MS116-32 is a thermal-magnetic manual motor starter designed to protect and control motors up to 15 kW. It provides integrated overload, short circuit, and phase failure protection combined with manual ON/OFF switching in a compact, durable device ideal for industrial environments.

Application:
Suitable for motor control panels, standalone motor setups, and machinery that demand reliable, fuseless motor protection and manual disconnect capabilities.

✔️ Key Features:

• Current Adjustment Range: 25.00 – 32.00 A

• Motor Power Rating: Up to 15 kW (400 V, AC-3)

• Trip Class: Class 10 – fast overload protection

• Short-Circuit Breaking Capacity: Up to 10 kA

• Phase Loss Protection: Built-in detection and safeguarding

• Manual ON/OFF Rotary Handle: Trip-free design for enhanced safety

• Compact and Robust: 45 mm width, DIN rail mountable

• IP20 Protection: Finger-safe terminals for user safety

• High Mechanical Durability: ≥ 100,000 operation cycles

• Optional Accessories: Auxiliary contacts, shunt trip, undervoltage releases available
